Sku: LAS000560
Category: Electric Bicycle Motor
Electric Bicycle Motor
Member exclusive coupon: LASPERKS
$25 OFF on Order $200

Coupon is available after your account is successfully activated.

• Free Delivery within 3-5 business days.
• Payment Cleared before 12pm PST will be shipped out in the same business day (Pre-Orders Excepted).
30-Day Warranty & Return Policy
TheLAShop eBike Kit fit for 26x4 inch Fat Bikes, with Front and Rear Hub options. 1500W 48V powerful brushless gearless hub motor makes your bicycle an electric power moped, accelerates the speed up to 34 mile/h, allow you to fully enjoy the pleasure of riding; Suitable for mountain bikes, road bikes and cruise bike.

Features:

  • Option - Front Hub Motor Kit with tire excluded, fit for 5 1/8" front dropout spacing & 26"x4" tire
  • Option - Rear Hub Motor Kit with tire excluded, fit for 6 11/16" rear dropout spacing & 26"x4" tire
  • Brushless and gearless hub motor for efficient running and converting bicycle to be electric bike
  • Dual mode controller works under Hall effect and non-Hall effect for extending bicycle life
  • Pedal assist system for sensing your pedal cadence and allowing you to ride electric bike comfortably
  • Brake levers for cutting off the power and braking for safety; CE certificated for quality assurance
  • Aluminum alloy frame for durability and LCD operation panel for displaying battery power and speed

Specifications:

Options Front Hub Rear Hub
Overall Size(Dia.xW) 22 7/16" x 3 1/4" (57 x 8.3 cm)
Suitable Tire Size(Dia.xW) 26" x 4.0" (66 x 10.2 cm)
Axle Length 7 7/8" (20 cm) 9 7/16" (24 cm)
Front Dropout Spacing 5 1/8" (13 cm) --
Rear Dropout Spacing -- 6 11/16" (17 cm)
Spokes Length 6 5/16" (16 cm)
Controller Size(LxWxH) 8 1/4" x 4 1/8" x 1 15/16" (21 x 10.5 x 5 cm)
The Number of Spokes 36
Controller Current Limit 35A
Controller Power 1500 W
Motor Power 1500 W
Motor Voltage 48 V
Suitable Battery Type and Parameters 48v20AH, about 40KM of travel.
Load Capacity 331 Lbs (150 kg)
Net Weight 23.4 Lbs (10.6 kg) 23.6 Lbs (10.7 kg)

Package Includes:

Option: Front Hub Option: Rear Hub
  • 1x 26" Front Wheel Hub with Brushless Hub Motor
  • 1x Battery Connection Cable
  • 1x Electric Controller
  • 2x Hand Brakes
  • 2x Handle Grips
  • 1x Thumb Throttle
  • 1x Controller Bag
  • 1x Set of Winding Pipe and Cable Ties
  • 1x PAS Sensor
  • 1x LCD Display
  • 1x Spare Fuse
  • 2x Terminal Boxes
  • 1x Manual
  • 1x 26" Rear Wheel Hub with Brushless Hub Motor
  • 1x Dual Mode Motor Controller
  • 2x Brake Levers
  • 2x Handle Grips
  • 1x Twist Throttle
  • 1x Controller Bag
  • 1x Winding Pipe
  • 10x Cable Ties
  • 1x PAS Sensor
  • 1x LCD Meter
  • 2x Wire Connectors
  • 1x Battery Connection Cable
  • 1x Fuse
  • 1x Spoke Key

Notice:

  • 1.Battery and charger are not included, please prepare them before using.
  • 2.The electric wheel is only applicable to conventional bicycles, not for tricycles, tractors, etc.
  • 3.Please go to automobile repair shops with standard business license for modification.
  • 4.For safety reasons, it is not recommended to use in rainy days and please wear a helmet before riding this electric bicycle for protection.
